您的位置:首页 >产品中心 > 交流风扇 > 92 x 92 x 38mm

9238 115V
30 ~ 46 CFM
  • Specification

    Model
    Bearing
    Voltage
    Freq
    Current
    Power
    Speed
     Air Flow
    Static
    Pressure

    Noise
    VAC
    Hz
    A
    W
    RPM
      CFM
    m3/min
    mm H2O
    dB-A
    9238B1HL
    Ball
    115
    50/60
    0.16/0.12
    11/8
    2350/2700
    38/46
    1.08/1.30
    3.5/4.2
    34/37
    9238B1HT
    Ball
    115
    50/60
    0.16/0.12
    11/8
    2350/2700
    38/46
    1.08/1.30
    3.5/4.2
    34/37
    9238B1ML
    Ball
    115
    50/60
    0.09/0.07
    6.5/5.3
    2200/2300
    35/37
    1.00/1.05
    2.9/3.0
    32/33
    9238B1MT
    Ball
    115
    50/60
    0.09/0.07
    6.5/5.3
    2200/2300
    35/37
    1.00/1.05
    2.9/3.0
    32/33
    9238B1LL
    Ball
    115
    50/60
    0.07/0.06
    5.2/4.3
    2100/2050
    33/33
    0.93/0.93
    2.6/2.2
    30/29
    9238B1LT
    Ball
    115
    50/60
    0.07/0.06
    5.2/4.3
    2100/2050
    33/33
    0.93/0.93
    2.6/2.2
    30/29
    9238S1HL
    Sleeve
    115
    50/60
    0.18/0.12
    14/10
    2200/2700
    37/46
    1.05/1.30
    3.2/4.3
    32/37
    9238S1HT
    Sleeve
    115
    50/60
    0.18/0.12
    14/10
    2200/2700
    37/46
    1.05/1.30
    3.2/4.3
    32/37
    9238S1ML
    Sleeve
    115
    50/60
    0.14/0.10
    9/7
    2050/2300
    32/37
    0.91/1.05
    3.0/3.5
    29/33
    9238S1MT
    Sleeve
    115
    50/60
    0.14/0.10
    9/7
    2050/2300
    32/37
    0.91/1.05
    3.0/3.5
    29/33
    9238S1LL
    Sleeve
    115
    50/60
    0.09/0.08
    6.7/5.5
    1950/1900
    31/30
    0.88/0.85
    2.3/2.0
    28/27
    9238S1LT
    Sleeve
    115
    50/60
    0.09/0.08
    6.7/5.5
    1950/1900
    31/30
    0.88/0.85
    2.3/2.0
    28/27

    All model could be customized. Please contact with YYC Sales.                         Safety:     UL/TUV/CE/CCC

    Specifications are subject to change without notice.


    Air Flow-Static Pressure Characteristics




      Frame: Aluminum alloy

      Impeller: PBT Plastic

      Protected: Impedance protected

      Connection: Lead Wire or Terminals

      Ball Bearing: -20°C to +70°C

      Sleeve Bearing: -10°C to +70°C

      Package: 50PCS/CTN
